iso900135um pi double sided pcb printed circuit board 0.1mm holes flexible pcb
PS: Due to picture page load is significantly slower, as the file requires an additional HTTP request to be sent to the server.
So we choose more text introduction as below.
---------------------------------------------------------------------------
Factory Overview
Abis Circuits Co., Ltd is a professional PCB manufacturer which was established on Oct, 2006 and focus on double side, Multilayer and HDI pcb mass production. We have two factories together, the factory in Shenzhen is specialized in small and middle volume orders and the factory in Huizhou is for big volume and HDI.
| Item | Shenzhen | Huizhou |
| Area | 10,000 Square meters | 60000 Square meters |
| Employees | 300 | 900 |
| Quality | 20 | 60 |
| Administration | 5 | 10 |
| Engnieering | 20 | 90 |
| Over Sales | 10 | 20 |
Flexible printed circuit board overview
-Definition
Flexible PCB – Flexible Printed Circuit, referred to as FPC.
A flexible printed circuit can be defined as an outline of conductive traces bonded on a flexible substrate. It is made into conductor circuit patterns using light pattern expose transfer and etching processes on the surface of a flexible substrate.
-Characteristics
Flex circuits widely used in mobile phones, cameras and smart wearable’s.
It can better fit wiring capability in spaces than the traditional rigid boards.Flexible circuit boards also have better resistance to high temperatures, shock and vibrations. it has good performance with design challenges such as: unavoidable crossovers, specific impedance requirements, elimination of cross talk, additional shielding and high component density.
-Classify
ABIS Flexible PCB Manufacturing Capacity
| Item | Speci. |
| Layers | 1~20 |
| Board Thickness | 0.1mm-8.0mm |
| Substrate Material | PI(0.5mil,1mil,2mil),PET(0.5mil,1mil) |
| Conductive Medium | Copper foil(1/3oz,1/2oz,1oz,2oz) Constantan Silver Paste Copper Ink |
| Max Panel Size | 600mm×1200mm |
| Min Hole Size | 0.1mm |
| Min Line Width/Space | 3mil(0.075mm) |
Maximum imposition size (single & double panel) | 610mm*1200mm(Exposure limit) 250mm*35mm(only develop test samples) |
Maximum imposition size (single panel & double panel no PTH self-drying ink + UV light solid) | 610*1650mm |
| Drilling Hole (Mechanical) | 17um--175um |
| Finish Hole (Mechanical) | 0.10mm--6.30mm |
| Diameter Tolerance (Mechanical) | 0.05mm |
| Registration (Mechanical) | 0.075mm |
| Aspect Ratio | 2:1(Minimum aperture 0.1mm) 5:1(Minimum aperture 0.2mm) 8:1(Minimum aperture 0.3mm) |
| SMT Mini. Solder Mask Width | 0.075mm |
| Mini. Solder Mask Clearance | 0.05mm |
| Impedance Control Tolerance | 士10% |
| Surface finish | ENIG, HASL, Chem. Tin/Sn |
| Soldermask/Protective Film | PI(0.5mil,1mil,2mil)(Yellow, White, Black) PET(1mil,2mil) Solder mask (green, yellow, black...) |
| Silkscreen | Red/Yellow/Black/White |
| Certificate | UL, ISO 9001, ISO14001, IATF16949 |
| Special Request | Glue(3M467,3M468,3M9077,TESA8853...) |
| Material Suppilers | Shengyi, ITEQ, Taiyo, etc. |
| Common Package | Vacuum+Carton |
| Monthly production capacity/m² | 60,000 m² |
Lead Time
Small Batch Volum ≤1 sq meter | Working Days | Mass Production | Working Days |
| Double Sided | 3-4 | Double Sided | 8-10 |
| 4-6 layers | 4-5 | 4-6 layers | 10-12 |
| 8-12 layers | 10-12 | 8-12 layers | 14-18 |
| 14-18 layers | 15-16 | 14-18 layers | 20-26 |
Quality Mission
FAQ
Q1: Are you a factory or trade company?
-Abis is a PCB/FPC/PCBA manufacturer/factory. We pecialize in
PCB/PCBA Board for over 10 years.
Q2: How can I get a quotation:
-Please send gerber file with format: .PCB / .P-CAD / .DXP / .Gerber
Q3: Can you manufacture my PCBs from a picture file?
-Yes, we can copy for you accordingly. Could you please provide a
sample via express?
Q4: Do you have PCB in stock?
-It depends on. Most of our PCB board are customized, which according to Gerber file.
. ABIS has samples in stock that could be sent to you for quality
checking always.
Q5: Is my PCB file safe if I send it to you for manufacturing?
-We respect customer's design authority and will never manufacture
PCB for someone else without your permission. NDA is acceptable.
Q6: Will my PCB files be checked?
-Checked within 12 hours. Once Engineer's question and working file
be approved, production will start.
Q7: What do you require in order to produce an assembly quotation?
-Bill of materials (BOM) detailing:
a), manufacturers parts numbers,
b), components suppliers' parts number (e.g. Digi-key, Mouser, RS )
c), PCBA sample photos if possible.
d), Quantity
Q8: Can I get a sample?
A: Yes, It's reasonable to get a sample to test our quality at
first.
Q9: What's your shipping way ?
1. We have our own forwarder to ship goods by DHL, UPS, FEDEX,
TNT,EMS.
2. If you have your own forwarder, we can cooperate with them.
Q10: Is there any discount for old cilents or reorder?
Yes, of course. Highly loyal customers could get a price discount as a reward for their loyalty
|
|
