Immersion Gold 3u'' 6 Layer PCB Board TG170 FR4 SMT Assembly PCB
Abis Circuits Co., Ltd is a professional PCB manufacturer in China,
Shenzhen. With 15 years+ development, we could make the PCB from 1L
to 20L, with monthly production capability of 60,000 square meters.
Abis Circuits is providing high-quality bare PCB and PCB assembly
service, including components sourcing, function test, conformal
coating, and complete assembly for clients all over the world, Our
main market is Europe, north USA, Australia, South America, and
Asia.
Product details:
| Layers: | 1 - 50 layer |
| board finishing types: | HAL leadfree hard gold: < 1 µ gold fingers: > 0.75 µ carbon ink tin min.: 0.60 µ max.: 1,19 µ OSP |
| base material: | FR 2, FR 4, CEM 1, CEM 3, flex, alu – 8 W / mK |
| hole size tolerance: | PTH: +/- 0.076 mm NPTH: +/- 0.05 mm |
| min. finished hole: | 0.1 mm |
| blind/buried holes: | 0.30 mm |
| hole to hole tolerance: | +/- 0.076 mm |
| board thickness: | ≤ 6 mm |
| line width/spacing: | ≤ 0.075 mmm |
| line width tolerance: | +/- 15 % |
| line space tolerance: | +/- 20 % |
| SMT pitch: | 0.20 mm |
| electrical testing: | test voltage: 50 - 250 V |
| nickel plating thickness: | min.: 2.54 µ max.: 7.60 µ |
| soldermask thickness: | 4 - 50 µm |
| soldermask ink: | different colours |
| board thickness tolerance: | +/- 10 % |
| outline tolerance: | +/- 0.1 mm |
| V-grooving tolerance: | +/- 0.1 mm |
| min. soldermask pitch: | 0.1 mm |
| base copper thickness: | 18 - 400 µ |
| flammability: | 94 V - 0 |
| thermal stress: | 288° C / 20 sec |
| outline profile: | punching, routing, v-cut |
| through-hole resistance: | < 300 ohm normal |
| twist and bow: | < 2 % |
| maximum panel size: | 476 mm x 620 mm |
Lead time:
| Board Type | Manufacturing Lead Time |
| Single Sided | 5 – 20 Days dependant on volume |
| PTH | 7 – 25 Days dependant on volume |
| Multilayer | 15 – 30 Days dependant on volume & Technology |
·
| Air Freight Lead Time – 4 Days |
| Sea Freight Lead Time – 30 Days |
| All Far East lead times are subject to customs clearance |
| Premium International shipments can be arranged by DHL, Fedex, UPS or TNT at extra cost |
FAQ:
Q1: How can I get a quotation:
. Please send gerber file with format: .PCB / .P-CAD / .DXP / .Gerber
Q2: Can you manufacture my PCBs from a picture file?
. Could you please provide a sample?
Q3: Do you have PCB in stock?
. Most of our PCB board are customized, which according to Gerber file.
. ABIS has samples in stock that could be sent to you for quality
checking always.
Q4: What board manufacturer do you use for FR4?
. Main Suppliers(FR4): Kingboard (Hong Kong), NanYa (Taiwan), and
Shengyi (China).
Q5: Will my PCB files be checked?
. Checked within 12 hours. Once Engineer's question and working
file be approved, production will start.
Q6: What do you require in order to produce an assembly quotation?
. Bill of materials (BOM) detailing:
a), manufacturers parts numbers,
b), components suppliers' parts number (e.g. Digi-key, Mouser, RS )
c), PCBA sample photos if possible.
d), Quantity
