    HASL Lead Free White Overlay FR4 Rigid Multilayer PCB

    Ask Lasest Price
    Certification : ISO14001, ISO9001, UL, cUL, TS16949
    Price : Customized
    Payment Terms : T/T, paypal, , Western Union etc.
    Supply Ability : 60,000sqm per month
    Delivery Time : 1-15 working days
    • Product Details
    • Company Profile

    HASL Lead Free White Overlay FR4 Rigid Multilayer PCB

    Rigid Board FR4 Multi Layer PCB With HASL-Lead Free Surface Finish In White Overlay


    1.Company introduction

    Abis Circuits Co.,Ltd is a professional PCB manufacturing in Shenzhen, China for more than 10 years which is focus on double side, Multilayer and HDI PCB mass production. Our company was founded in 2006. We have two factories together and offer a wide range of services from quick turn, PCB prototypes to large volume PCB manufacturing. Our aim is help the clients gain more competitive strength and bring more mutual benefit to each other. All clients will be served well.

    2.Factory

    Operation plant space:
    (I) 10000 Square meters
    (II) 60000 Square meters
    Employees:
    (I) 300 Man Powers
    (II) 900 Man Powers
    Engineer Technical:
    (I) 20 QA QC Engineers
    (II) 60 QA,QC Engineers
    3.Technological capability
    NoItemsCapability
    1Layers1-20
    2Base MaterialFR4, High Tg FR4, Halogen Free, Isola, Rogers, Aluminium, etc
    3Max. Size600mm x 1200mm
    4Finished Board Thickness0.2mm-8.0mm
    5Copper Thickness0.5oz-10oz
    6Surface FinishingHASL, Lead Free HASL, Immersion tin, Immersion gold, Gold plating, Immersion silver, OSP, etc.
    7Min. Trace Width/Space0.075/0.075mm
    8Min. Finish Holes Size0.1mm for mechanical holes
    9Diameter Tolerance0.05mm for mechanical
    10Registration0.075mm for mechanical
    11Soldermask ColorGreen, White, Black, Red, Yellow, Blue
    12Silkscreen ColorWhite, Black, Yellow, Blue
    13Impedance Control+/-10%
    14Profiling PunchingRouting, V-CUT, Chamfer
    15Special HolesBlind/Buried holes, Countersunk holes
    16Reference StandardIPC-A-600H Class 2, Class 3, TS16949
    17CertificateISO14001, ISO9001, UL, cUL
    18PCB Package

    Vacuum & Carton


    4.Lead time


    CategoryQuickest Lead timeNormal Lead TimeMass Production
    2 Layers24hrs3-4 working days8-15 working days
    4 Layers48hrs3-5 working days10-15 working days
    6 Layers72hrs3-6 working days10-15 working days
    8 Layers96hrs3-7 working days14-18 working days
    10 Layers120hrs3-8 working days14-18 working days
    12 Layers120hrs3-9 working days20-26 working days
    14 Layers144hrs3-10 working days20-26 working days
    16-20 LayersDepends on the specific requirements
    Above 20 LayersDepends on the specific requirements


    5.Certificate



    6.FAQ


    Q1: What service do you have?
    -We provide turnkey solution including PCB fabrication, SMT, plastic injection & metal,final assembly, testing and other value-added service.


    Q2: What is needed for PCB & PCBA quotation?

    -For PCB: Quantity, Gerber file and technic requirements(material,size, surface finish treatment, copper thickness,board thickness etc.).
    -For PCBA: PCB information, BOM,Testing documents.


    Q3:How to keep our product information and design file secret ?
    -We are willing to sign a NDA effect by customers side local law and promising tokeep customers data in high confidential level.

    Q4,:What are the main products of your PCB/PCBA services?
    -Automotive, Medical, Industry Control,IOT,Smart Home,Military.

    Q5: What is your minimum order quantity (MOQ)?
    -Our MOQ is 1 PCS, sample and mass production all can support.


    Q6: Are you factory?

    -We have two factories together , the factory in Shenzhen is specialized in small and middle volume orders and the

    factory in Huizhou is for big volume and HDI.


    Q7: What do you require in order to produce an assembly quotation?
    -Bill of materials (BOM) detailing:
    a), manufacturers parts numbers,
    b), components suppliers' parts number (e.g. Digi-key, Mouser, RS )
    c), PCBA sample photos if possible.
    d), Quantity
