RoHS Multi Layer PCB

RoHS Multilayer PCB for Air Conditioner/Motherboard/Power Supply PCB Board

ABIS CIRCUITS CO., LTD

Created in 2006,as a long history China based PCB supplier, ABIS manufactures different kinds of printed circuit boards, including MCPCB,CEM-1,CEM-3,and FR4,FR-4 high Tg, Rogers, Teflon, Arlon ets special material.
ABIS has set up two PCB factories in China: one for MCPCB producing, quick turn and small volumn making, and another for mass production. Currently, ABIS modern plants occupy total 10000 s.q.m facility, with more than 1100 stable and experienced workers. Professionalism and continuous optimization of manufacturing processes have positioned ABIS as a reliable and favorite partner for global companies.

specification

ltem	apacity
Raw material	CEM1,CEM3,FR1 FR4,Rogers,Teflon, etc.
Layer	1 Layer-20 Layer
Min.Line width/space	3mil 3mil (0.075mm/0.075mm)
Min.hole size	0.1mm(drilling hole)
Max.Board size	1200mm*600mm
Finished board thickness	0.2mm-6.Omm
Cooper foil thickness	18um- 28oum (o.5oz-8oz)
NPTH Hole Tolerance	+/-0.075mm
PTH hole Tolerance	+1-0.05mm
Outline tolerance	+/-0.13mm
surface finished	Lead-Free HASL, immersion gold(ENIG), Immersion silver,OSP, gold plating, gold finger,Carbon INK
Impedance Control Tolerance	+/-10%
Production capability	50,000 s.q.ml month

ltem	Capacity
Rawmaterial	Aluminumbase,Cooperbase
Layer	1-8Layer
Min.Linewidth/space	4mi/4mil(O.1mm/0.1mm)
Min.holesize	12mil(0.3mm)
Max.Boardsize	1200mm560mm(47in22in)
Finishedboardthickness	0.3-5mm
Cooperfoilthickness	35um-210um(10Z-60Z)
Remainthicknesstolerance	+/-0.1mm
Holepositiontolerance	+/-0.05mm
Routingoutlinetolerance	+/-0.15mm
Punchingoutlinetolerance	+/-0.1mm
Surfacefinished	Lead-freeHASL,Immersiongold,immersionsilver,OSP,etc
MCPCBProductioncapability	10,000a.q.m/month

Logistics Service

RoHS Multi Layer PCB

On time delivery rate is more than 95%

1.24 hours fast turn for double side prototype PCB, 48 hours for 4-8 layers prototype PCE.

2.1 hour for quotation 2 hours for engineer question. Complaint feedback within 2 hours.

3.7-24 hours for order service.

4.7-24 hours for technical support.

5.7-24 hours manufacturing operations.

Go Green !

Our Plant have invested huge money for the waste water and exhaust gas process to reduce thepollutant emission, Through survey and investigation, we decided to adopt environment-friendly andenergy-efficient technologies and techniques to our plants.

The above mentioned, the application of technologies and techniques as described below indicatesthat Core indeed assumed its social responsibility of environment protection, by green production andreducing pollution and carbon emission.
