ABIS CIRCUITS CO., LTD
Created in 2006,as a long history China based PCB supplier, ABIS manufactures different kinds of printed circuit boards, including MCPCB,CEM-1,CEM-3,and FR4,FR-4 high Tg, Rogers, Teflon, Arlon ets special material.
ABIS has set up two PCB factories in China: one for MCPCB producing, quick turn and small volumn making, and another for mass production. Currently, ABIS modern plants occupy total 10000 s.q.m facility, with more than 1100 stable and experienced workers. Professionalism and continuous optimization of manufacturing processes have positioned ABIS as a reliable and favorite partner for global companies.
|
Items |
Single/Double-sidedBoard/MutilayerBoard/FPC(1-24Layer) | ||
|
BaseMaterials |
FR-4(HighTG150*-170^),FR1.Aluminum,CEM-3,BT,94V0 | ||
|
Finishcopperthickness |
Outer6OZ,nner40Z | ||
|
Surfacefinish |
ENIG,ImAg.ImSn,0SP,HASL,Platinggold | ||
|
FinishedBoardSize |
MaxDouble-sidedBoard |
640mmX1100mm | |
|
MaxMutilayerBoard |
640mmX1100mm | ||
|
FinishedBoardHoleSize(PTHHole) |
MinFinishedBoardHoleSize |
0.15mm | |
|
ConductorWidthandSpacing |
MinConductorWidh |
0.01mm | |
|
MinConductorSpacing |
0.01mm | ||
|
ThicknessofPlatingandCoatingLayer |
PTHwallCopperThickness |
>0.02mm | |
|
TinSolderThickness(HotAlrLeveling) |
>0.02mm | ||
|
Nickl/GoldThickness |
Forcustomerspecialneed | ||
|
NicklPlatingLayer |
>2um | ||
|
GoldPlatingLayer |
>0.3um | ||
|
BareBoardTest |
SinglesideTest |
MaxTestPoint |
20480 |
|
MaxBoardTestSize |
400mmx300mm | ||
|
DoubleSldeTest |
MaxTestPoint |
40960(GeneralUse) | |
|
4096(SpecialUse) | |||
|
MaxBoardTestSize |
406mmx325mm | ||
|
320mmx400mm | |||
|
MinTestpitchofSMT |
0.5mm | ||
|
TestVoltage |
10-250V | ||
|
MechanicalProcess |
Chamfer |
20*,30*,45*,60* | |
|
AngleTolerance |
| ||
|
DeepnessTolerance |
士0.20mm | ||
|
V.CutAngle |
20",30*,45* | ||
|
BoardThickness |
0.1-3.2mm | ||
|
ResiduesThickness |
:0.025mm | ||
|
CellParapositionPrecision |
士0.025mm | ||
|
ToleranceofOut-shapeProcess |
土0.1mm | ||
|
BoardWarp |
MaxValue |
0.7% | |
|
|
MaxPlottingArea |
66mmX558.8mm | |
Factory
PCB Assembly Services
To deliver real value and convenience to our PCB fabrication clients, we expand our business to components sourcing and turnkey PCB assembly services ranging from the prototype, low-to-middle volume to high volume up to 1 million pcs. We can mount components on circuit boards using surface mount technology (SMT),through-hole technology (THT), and manual insertion:
- High-quality assembly services with short lead times
- No minimum order
- No additional charge for stencils
- Free DFM Check
- 100% AOI test and X-Ray test for BGAs package
- Function tests & IC programming based on custom requirements
FQA
Q1: How can I got quotation:
. Please send gerber file with format: .PCB / .P-CAD / .DXP / .CAD / .Gerber
Q2: Can you manufacture my PCBs from a picture file?
. Could you please provide sample?
Q3: Do you have pcb in stock?
. Most of our pcb board are customised, which according to gerber file.
. ABIS have sample in stock could sent to you for a quality checking always.
Q4: What board manufacturer do you use for FR4?
. Main Suppliers(FR4): Kingboard (Hong Kong), NanYa (Taiwan) and Shengyi (China).
Q5: Will my PCB files be checked?
. Checked within 12 hours. Once Engieer question and working file checked, production will start.
Q6: What do you require in order to produce an assembly quotation?
. Bill of materials (BOM) detailing:
a), manufacturers parts numbers ,
b), components suppliers' parts number (e.g. Digi-key, Mouser, RS )
c), PCBA sample photos if possible.
d), Quantity
Q7: Does ABIS CIRCUITS bevel gold fingers?
. Yes. A standard 45-degree bevel, also bevel at 15 or 30 degrees upon request. For multi-layer board, please ensure there is adequate back set for the bevels.
Q8: My assembly company need the PCBs as panelized, can you do this for me?
. Yes. We can panelize your circuits upon your request.
|
|
